Fiber profile:

Step-index multimode

Fiber core:

Low OH silica

Fiber cladding:

Doped silica

Fiber buffer:

Polyimide

Fiber assembly jacketing:

Silicone monocoil

Fiber diameter:

600 μm

Fiber assembly length:

2.0 meters (+/- 5%)

Fiber bundle:

7 angled polished fibers around 1 flat polished

Operating temperature:

-50 oC to 80 oC (fiber assembly); -50 oC to 200 oC

Numerical aperture:

0.22 +/-0.02 (before angle polishing)

Wavelength range:

VIS/NIR (400-900 nm)

Probe ferrule:

1/4" OD x 3.0" Stainless Steel with adjustable BK7 glass window
