TUNABLE LASERS |
|
Gain-switched
|
TiSon GSB New |
710-890 nm |
up to 1 kHz, > 200 uJ and < 10 ns at 800 nm, automatic, PC controlled wavelength tuning |
'TECHNOLOGY'-series lasers |
| Q-switched |
TECH-263 |
263 nm |
Basic |
10 uJ@1 kHz or 25 uJ@1 kHz, 4 ns |
Beam quality - TEM00, M2 < 1.2
Long term stability < 2% / 8 hrs
Range of pulse repetition rate:
0 - 4 kHz (for Basic andAdvanced)
0 - 1 kHz (for Specific andExpress)
Operating voltage - 24 V +/- 10%
|
| Advanced |
50 uJ@1 kHz, < 3 ns |
| TECH-351 |
351 nm |
Basic |
50 uJ@1 kHz or 125 uJ@1 kHz, 5 ns |
| Advanced |
200 uJ@1 kHz, < 5 ns |
| TECH-527 |
527 nm |
Basic |
250 uJ@1 kHz, 5 ns |
| Advanced |
500 uJ@4 kHz, 5 ns |
| Express |
500 uJ@1 kHz, < 3 ns |
| Specific |
1000 uJ@1 kHz, > 7 ns |
| TECH-1053 |
1053 nm |
Basic |
500 uJ@1 kHz, 6 ns |
| Advanced |
1000 uJ@4 kHz, 6 ns |
| Express |
1000 uJ@1 kHz, < 4 ns |
| Specific |
2000 uJ@1 kHz, > 10 ns |
MULTI-WAVELENGTH LASERS |
| Q-switched |
TECH-263 Basic - 3 wavelength laser |
> 10 uJ at 263 nm, > 100 uJ at 527 nm, > 100 uJ at 1053 nm |
| TECH -351 Basic - 3 wavelength laser |
> 120 uJ at 351 nm, > 100 uJ at 527 nm, > 150 uJ at 1053 nm |
| TECH -527 Basic - 2 wavelength laser |
> 200 uJ at 527 nm, > 200 uJ at 1053 nm |
ULTRAVIOLET LASERS |
| Q-switched |
DTL-375QT |
355 nm |
20 uJ at 1 kHz |
Pulse width < 6 ns at 1 kHz.
Range of pulse repetition rate:
external - from single pulse to 30 kHz
through RS-232 - 0.01 - 30 kHz
internal without PC - 1 kHz.
|
| GARNET |
20 uJ at 200 - 2000 Hz, external triggering. Industrial model for OEM. |
GREEN LASERS |
| Q-switched |
DTL-314QT |
532 nm |
25 uJ at 1 kHz |
Pulse width < 8 ns at 1 kHz.
Range of pulse Repetition Rate:
external - from single pulse to 30kHz
through RS-232 - 0.01 - 30kHz
internal without PC - 1 kHz. |
| Single-Frequency CW |
SLM-417 |
532 nm |
20 and 50 mW, manual power adjustment, CDRH-compliant |
Single longitudinal mode
Line Width 0.00001 nm
Low noise (<0.1% RMS)
Coherence length >50m |
| LCM-S-111 |
10, 20 and 50 mW, 4.5 - 6 V DC / 4 A. Laser module for OEM |
| LCM-S-111-R (for Raman) |
10 and 20 mW, 4.5 - 6 V DC / 4 A. High tolerance to back reflections. Laser module for OEM. |
| Continuous Wave |
DTL-413 |
527 nm |
200, 350, 500, 1000 and 1500 mW. Noise level <1% RMS, RS-232 control |
| LCM-T-111 |
532 nm |
1, 10 and 20 mW, 3.3 - 3.5 V DC / +/- 1.4 A. Laser module for OEM. |
| LCM-T-111-AP |
10 and 20 mW, 5 V DC / +/- 1.4 A, power adjustment, TTL modulation. Laser module for OEM. |
| LCS-T-11 |
3 mW, AC Power Supply, CDRH-compliant |
INFRARED LASERS |
| Q-switched |
DTL-324QT |
1064 nm |
100 uJ at 1 kHz |
Pulse width < 10 ns at 1 kHz.
Range of pulse Repetition Rate:
external - from single pulse to 30kHz
through RS-232 - 0.01 - 30kHz
internal without PC - 1 kHz. |
| Single-Frequency CW |
LCM-S-112 |
1064 nm |
100 mW, 4.5 - 6 V DC / uJ 4A. Laser module for OEM. |
Single longitudinal mode
Line Width 0.00001 nm
Low noise (<0.1% RMS)
Coherence length >50m |
| Continuous Wave |
DTL-423 |
1053 nm |
300, 1000, 2000 and 2500 mW |
Noise level <0.5% RMS
RS-232 control |
| DTL-322 |
1064 nm |
300, 1000 and 2000 mW |
| LCM-T-112 |
10, 100 and 200 mW, 3.3 - 3.5 V DC / +/- 1.4 A. Laser module for OEM. |
| LCS-T-12 |
50 mW, AC Power Supply, CDRH-compliant |
